Specifications
Keyboard
|
88-key, Tri-sensor scaled hammer action keyboard
|
---|---|
Touch Response
|
3 sensitivity levels, Off
|
Sound Source
|
Linear Morphing AIF
|
Maximum Polyphony
|
128
|
Tones
|
18 built-in tones: Grand Piano (Modern, Classic, Mellow, Bright, Variation), Electric Piano, FME Piano, 60’s E. Piano, Harpsichord, Vibraphone, Pipe Organ, Jazz Organ, Electric Organ 1, Electric Organ 2, Strings 1, Strings 2, Bass 1, Bass 2
* Bass 1 and Bass 2 are special low-range tones for use with Split. |
Layer/Split
|
Layer, Split
|
Digital Effects
|
Reverb (4 types), chorus (4 types), brilliance, DSP (built into some tones), acoustic resonance system
|
Built-in Songs
|
60 (Music Library)
|
Song Expansion
|
1 song (65KB maximum)
|
Lesson Function
|
Part on/off (Lesson part: right hand/left hand)
|
Metronome
|
Beats: 0, 2, 3, 4, 5, 6 (Tempo range: quarter note = 20 to 255)
|
Recorder
|
2 tracks x 1 song, approximately 5,000 notes maximum, real-time recording/playback
|
Other Functions
|
|
Key Transpose
|
25 steps (-12 to +12 semitones)
|
Tuning Control
|
A4 = approximatery 440 Hz ± 99 cents
|
Pedals
|
Optional 3 pedal unit (SP-32) support
* damper = half-pedal operation |
MIDI
|
|
Speakers
|
[13cm/6cm (rectangular)] x 2
|
Amp Output
|
8W+8W
|
Input/Output Terminals
|
* USB cable (A-B type) required to use USB terminal for computer connection. |
Power Requirements
|
AC adaptor: AD-A12150LW
|
Dimensions (W x D x H)
|
1,322 x 286 x 135mm (main unit only)
1,322 x 286 x 759mm (with optional CS-67PWE/67PBK stand) * Excluding music stand, and other projections |
Weight
|
11.2kg (main unit only)
21.2kg (with optionally available CS-67PWE/67PBK stand) |
Body Color/Finish
|
PX-135BK: Pearl Black finish
PX-135WE: Cool white finish |
Included Accessories
|
Pedal (SP-3), score book, music stand, AC adaptor, dust cover
|
EAN code
|
PX-135BK: 4971850361695
PX-135WE: 4971850361701 |
