A total of 11 delay models include tape, analog and reveres etc. provide best tone of full direction. Either instrument input or loop jacks of guitar amp can be connected to TIME FORCE with -10dB or +4dB input/out pad, and kill dry functions. Flexible I/O jacks detect the stereo and mono connections automatically, which enable more routing possibilities. 40 seconds in stereo loop station make the practice full of fun. Tail function makes effect sound fade out when the effect is off. Tap tempo with different sub division can input the delay time easily.
- 11 Delay effects
- True stereo signal processing
- Automatic I/O detecting circuit
- Tail keeping function
- Kill dry function
- Up to 9 storable user presets plus manual mode
- Individual TAP tempo function
- Easy switching between manual and presets
- Large color LCD panel (128×128), graphic interface making the overall operation easy and intuitive
- New generation 32-bit DSP, high performance 24-bit 44.1 kHz AD/DA
- Input/output level for send/return
- Buffered or true bypass
- Runs on battery or AC power
- Effects types: 11 modeling delay modes
- Presets: up to 9 storable user presets plus manual mode
- Sampling frequency: 44.1 kHz
- A/D converter: 24-bit
- Signal processing: 32-bit
- Frequency response: 20Hz-2000Hz ±1dB
- THD+N: 93dBu (<0.003%) A-Weighting
- Dynamic Range: 100dB
- Input: -20dBV@1MO
- Output: -10dBV(Output load impedance of 10 KOor more)
- Display: 128*128 TFT
- Power: 9V DC (9V battery or optional ACD-007A Adaptor)
- Dimension: 125(L) * 108(W) * 57(H) mm
- Weight: 390 g
