Quick Overview
features
- Using Single Chip Micro Computer (MCU) controller. The delay time is programmable and more precise reliably:
- 8 channels and 20kg Power supply. Each channel has independent EMI-Power Filter, CE certificate approved:
- Using Triphase 5-pin professional socket, Diphase and Triphase are compatible:
- LED voltage meter and LED visual operational interface display the voltage of each line, delay time, power sequence etc:
- With USB lamp:
- Every output channel can be turned of immediately in urgent:
- Password function:
- Programming function. Remote control function: The remote control distance is up to 1km:
- Link In and Link Out function:
- Overload Voltage Alarm function: It alarms whenever the voltage is out of the range which you setup:
- Multi-sockets meet your different plugs:
Specifications:
- Voltage: Diphase 110V or 220V ( +/-20%), Triphase 190V or 380V
- Power Frequency: 50Hz or 60Hz ( +/-5%)
- Power Input: Diphase and Triphase, 5-pin industrial socket, 32A input
- Protection: Overload current protection and short protection
- Display: 3 characters LED voltage meter 3 characters LED program screen
- Voltage Meter: 3 characters LED real-time display, +/-1% no-load accuracy, +/-1% accuracy of
- full- load Sequencing Channel: 8 pairs of sequence channels of independent control.
- Power Output: 8 pairs of outputs, connected with audio load, each pair of audio output will not exceed 40A, connected with pure resistance.
- Time Sequence: Programable
- Single-way Switch: Withisingle-way switch, any channel can be turgently Voltage setup error 1%
- Overload voltage accuracy: +/-1% of no load accuracy, +/-1% of accuracy of full load
- Grounding Resistance: R<100mΩ
- The height of Unit: 2U
- Product Dimension (HxWxD: 482x400x88mm
- Shipping Dimension (HxWxD) : 1PC: 607-183-524mm 3PCS: 622-599-539mm
- Net Weight: 10.25kg
- Gross Weight: 1PC: 11kg 3PCS: 33kg
